375kVA Weichai Silent Diesel Generator Set
  • Koten
  • China
  • 20-25days
  • 200set per month

1- Weichai engine diesel generator set powered from 20kva to 2000kva.
2- Alternator optional: Koten/Leroysomer/Stamford.
3- Controller optional: Smartgen/Deepsea/ComAp.
4- 8hrs fuel tank as standard optional 12hrs or 24hrs big fuel tank capacity.
5- 1 Year global warranty.

375kva weichai diesel generator

Koten Power Diesel Generator Set Powered By Weichai Engine.

50Hz ,400V Three Phase Prime Power 300KW / 375KVA.


Features & Benefits Of Weichai Engine:

  • Easy service and maintance.

  • Adapt to harsh environment high altitude, extreme hot and cold environment and maintance.

  • 24/7 global after-sales service and spare parts supply.

  • Full range.

  • 50 degree ambient temperature approved.

  • Low operation cost.

Aplication:

Koten gensets had been widly applicated for hospital, factories, shopping mall, hotel, banks, telecommunictaion, residential, airport, stations, military ect.

1,Technical data.


Diesel Genset
ModelKW375D5
Frequency50Hz
Phase3Ph
Voltage230/400V
Prime Power300 kW/375 kVA
Standby Power330 kW/412.5 kVA
Fuel Tank Capacity8hrs

Engine Datesheet
Engine BrandWEICHAI
Engine ModelWP12D353E200
Engine speed1500rpm
Rated power320 kW
No.of Cylinder6
Bore 126mm
Strock155mm
Displacement11.596L

Fuel Comsuption (L/Hr)
100% Prime power77.9
75% Prime power58.4
50% Prime power38.9

Alternator Optional
Alternator BrandKoten/Leroysomer/Stamford

Controller Optional
Controller BrandSmartgen/ComAp/Deepsea

Genset Dim and Weight
Dim4212*1500*2236mm
Weight3700kgs


2. Genset Controller:

375kva weichai diesel genset

3. Genset Configuration:

    Standard:

  • Genset coupled with Original Cummins engine with heavy-duty air filter, oil filter, fuel filter, fuel and water separator. Standard Koten brand brushless ac alternators. Alternator optional for Stamford, Leroy Somer, Marathon, Meccalte.

  • Large size radiator.

  • Heavy duty antivibration pad.

  • Heavy duty steel base frame with 8 hours continues working fuel tank.

  • The thickness of the canopy is 2mm at least with high quality paint materials and strict powder paint processing.

  • High quality door locks and hinges and 180° revolvable with disassemble door for easy maintenance.

  • large-scale impedance combined type muffler with high quality soundproof and insulation materials to ensure the low noise level for the generators.

  • High quality maintenance-free battery with connecting cables.

  • Standard mcb or mccb with brand Delixi. Optional for Chint,ABB ect.

  • Standard Smartgen HGM6120N control moduel with AMF function, Optional for Deepsea, ComAp,  Datakom,Deif ect.

  • Genset standard with battery charger and ATS connection port.

  • Genset standard with 4 lift eyes, lift pockets on the base frame and lifting port on the top of the canopy which ensure the gensets can be transport easily.

Optional:

  • Water jacked heater.

  • Radiator water level sensor.

  • Oil heater.

  • Space heater.

  • ATS and synchronization panels.

  • Daliy fuel tank.

  • PMG for alternator.

WP12D353E200 diesel generator

375kva weichai diesel generator
